MCVEVP – Intel PSG Cyclone V Evaluation Platform
Easy Start and Integration of the Cyclone V SoM

The MCVEVP supports a quick start-up of SoC-FPGA projects and can easily be used as a fast-prototype platform.
MCV offers the full flexibility of the Altera Cyclone V SoC FPGA family.It integrates an ARM-based hard processor system (HPS) consisting of processor, peripherals, and memory interfaces with the FPGA fabric using a high-bandwidth interconnect backbone. The Altera SoCs combine the performance and power savings of hard intellectual property (IP) with the flexibility of programmable logic.
Features
- 2x HPS Gigabit Ethernet
- HPS USB
- 2x UART
- 2x CAN
- TFT connector
- Touchscreen controller I²C
- HSMC extension connector
- 3x PMOD extension connectors
- microSD-card slot
Block Diagram

Pictures


Order Codes
MCVEVP-2DB0
- 5CSEBA2U23C8N
- 600MHz speed
- 1GB DDR3 SDRAM
- 4GByte eMMC
- 0°C...+70°C
MCVEVP-6DB0
- 5CSEBA6U23C7N
- 800MHz speed
- 1GB DDR3 SDRAM
- 4GByte eMMC
- 0°C...+70°C
MCVEVP-X2DB0
- 5CSXFC2C6U23C7N
- 800MHz speed
- 1GB DDR3 SDRAM
- 4GByte eMMC
- 0°C...+70°C
MCVEVP-X6DB0
- 5CSXFC6C6U23C7N
- 800MHz speed
- 1GB DDR3 SDRAM
- 4GByte eMMC
- 0°C...+70°C
MCV features additional hard logic such as PCI Express® Gen1, multiport memory controllers, and high-speed serial transceivers. Our SoCs drive down power and cost while enabling performance levels required by cost-sensitive applications. Due to the flexibility of the MCV concept 25KLE, 40KLE, 85KLE and 110KLE FPGAs are supported by MCV.
